LU960UST is built with the native resolution switch function so users can change the native resolution from WUXGA into 1080P. When the native resolution is set at 1080P, the vertical lens shift function will be enabled for users to perfectly align images in any challenging venue such as when lights or vents that are located at the ceiling mounting site. Lens shift can move projected images up and down by 5% of screen height.
LU960UST is built with the native resolution switch function so users can change the native resolution from WUXGA into 1080P. When the native resolution is set at 1080P, the vertical lens shift function will be enabled for users to perfectly align images in any challenging venue such as when lights or vents that are located at the ceiling mounting site. Lens shift can move projected images up and down by 5% of screen height.
Display
Brightness (ANSI lumens)
5200
Native Resolution
WUXGA (1920×1200)
Native Aspect Ratio
16:10
Contrast Ratio (FOFO)
3,000,000:1
Display Color
30-bit (1.07 billion colors)
Light Source
Laser
Light Source Life
a. Normal 20000 hrs, b. ECO 38000 hrs, d. Dimming 75000 hrs
Optical
Throw Ratio
0.25
Zoom Ratio
Fixed
Lens
F/# = 2.0,f = 2.44 mm
Projection Offset (Full-Height)
122%
Rec. 709 Coverage
92%
Picture Modes
3D, Bright, DICOM SIM, HDR10, HLG, Presentation, Simulator, sRGB, User 1, User 2, Video
Compatibility
Input Lag
8.3 ms (1080P 120Hz)
Resolution Support
VGA (640 x 480) to 4K UHD (3840 x 2160)
Horizontal Frequency
15K~135KHz
Vertical Scan Rate
23~120Hz
